12A/90V Fiber Diode Driver Power Supply for Hair Removal Device
Fiber Diode Laser Hair Removal Power Supply 12A/90V Large Power
Product Name | 12A/90V Diode Driver Power Supply |
Model | LD808-GL90012 / LD808-WL90012 |
Dimension(L*W*H) | 324*183*69mm |
Weight | 2.7kg |
Input Voltage | AC220V ±20% / AC110V ±10% 50HZ |
Output Voltage | 30-90V |
Output Current | 0~12A |
Output Frequency | 1~10Hz |
PWM duty cycle | Max. 60% |
Pulse rising time | |
Working Temperature | 10~50 Degree |
Humidity | ≤85% |
Product Information
It is designed for fiber diode laser, upto 400W fiber. it is
special for 12A laser, upto 90V load.
Product Features
- Pulse current output
- Over voltage protection
- Over current protection
- High temperature protection
- TTL control interface standard
- Input 0-5V analog voltage corresponding to the 0-12A output
- Fast pulse rising time
Attention
- Input AC220/110V should be correct.
- At least 2.0 square meters cable for output to laser module.
- To reduce interferenceIn,about the layout of the whole machine, strong electric wires
should be separated from the weak signal lines.
- Please keep the environment dry and clean to avoid high voltage
leakage.
- In the complete layout, the power must be placed in a
well-ventilated location.
- Operating Humidity 20~90%RH,without dew.
- Storage Temperature, Humidity -40~+85°C, 10~95%RH.
The production process
FAQ
1. F: Are you trading company or manufacturer ?
A: We are manufacturer.
2. F: How long is your delivery time ?
A: Small order less than 10 days, large quantity less than 30 days;
customized products 30 working days.
3. F: Which way to deliver the goods?
A: usually by DHL, Fedex
4. F: Do you provide sample? is it free ?
A: We provide sample, it is not free.
5. F: What is your payment terms?
A: T/T or Western Union
6. F: How long is the warranty?
A: For electronic products is one year from delivery date.
7. F: Can you design control system? is it free?
A: We always customize system or power supply, it is free for
special order.
8. F: Could we download program if its function changed?
A: For new program, we can teach you how to download to board
yourself, but it is not a commitment to every customer.
